Varm Commercial Pool Series

Overview

The Commercial Pool Series is engineered for pools of 40 to 500 m³ in hotels, water parks, sports complexes and leisure facilities. Six models with nominal heating capacities of 26, 51.5, 75, 100, 121 and 145 kW keep large volumes of pool water at a stable temperature of up to 43 °C while achieving COP values of 6.0-6.2 at nominal conditions (27 °C air, 26 °C inlet water), sharply reducing the running costs of heated commercial pools.

All models operate between -7 and 43 °C ambient, run on 380-400 V three-phase supply and use R410A refrigerant. A titanium heat exchanger in a PVC housing withstands chlorinated and salt water, and IPX4-rated cabinets are designed for permanent outdoor plant areas. Sound levels range from 56 dB(A) on the 26 kW unit to 66 dB(A) on the 145 kW unit, and water connections scale from G1½" and G2" threaded fittings to DN110 PVC flanges with a water pressure drop of only 45-50 kPa.

Nominal water flow rates run from 11.2 to 62.4 m³/h, so the units tie easily into existing filtration circuits, and several units can be combined for the largest facilities. Weights range from 135 to 465 kg. Varmeks' engineering team supports model selection based on pool volume, indoor or outdoor location, operating season, pool cover and target water temperature.Nominal water flow rates run from 11.2 to 62.4 m³/h, so the units tie easily into existing filtration circuits, and several units can be combined for the largest facilities. Weights range from 135 to 465 kg. Motiontec Energy's engineering team supports model selection based on pool volume, indoor or outdoor location, operating season, pool cover and target water temperature.
